Your Project Concerns vs. Our Engineering Solutions
| Your Concerns | Our Solutions |
| Safety Hazard: Risk of luminaire carriage drop | Drive self-locking, braking, and top latching serve distinct lifting-control and ring-support functions. |
| Operational Jamming: Winch or pulley seizure rendering lowering impossible | Moving parts available in stainless‑steel grades (304/316/316L) to mitigate corrosion‑induced jamming and ensure full‑lifecycle reliability. |
| Installation Inaccuracies: Costly on-site rework from poor fit-up | Flange flatness ≤0.5 mm helps reduce fit-up deviations and on-site adjustment. |
| High Service Overhead: Expensive aerial lift rentals for routine maintenance | Ground-level lowering reduces reliance on aerial access equipment for routine luminaire maintenance. |
| Submission Delays: Project bottlenecks from missing compliance paperwork | Agreed English engineering documents support tender submissions and client technical reviews. |
| Civil Work Redundancy: High foundation costs for separate infrastructure poles | Optional lighting, surveillance, and sensor integration can reduce separate poles and foundations. |
1. Multiple Safety Functions with Factory Acceptance Testing
Worm-gear self-locking, braking, and automatic top latching provide distinct motion-control and ring-support functions. Every unit undergoes full-stroke and applicable functional checks before dispatch, with traceable inspection records.
2. Comprehensive Engineering Documentation Package for Bidding & Compliance
An agreed English documentation package may include structural calculations, lifting-system verification, foundation reactions, and applicable inspection reports, supporting tender submissions and technical reviews.
3. Multi-Functional Integration: Unified Pole for Lighting & Security
A single structural shaft supports luminaires, PTZ cameras, perimeter radar, and environmental sensors—eliminating redundant poles and duplicate foundations, shortening project timelines and reducing total costs.
4. High-Precision Manufacturing for Seamless On-Site Installation
Flange flatness ≤ 0.5mm, shaft straightness ≤ L/750, bolt hole deviation ±1.5mm—seamless plug-and-play on-site. Multi-section slip-joint coaxiality QC ensures smooth carriage operation, eliminating batch-installation rework.
5. Multi-Zone Corrosion Protection with Moving-Part Reliability
Corrosion protection is configured for the project environment. Wire ropes, pulleys, shafts, and brake-related components are selected individually for strength, corrosion resistance, and wear.
|
|
1. Electromechanical Integration & Commissioning Capabilities, Distinct from Pure Structural Steel Fabricators
Going far beyond basic steel pole fabrication, we possess full in-house assembly capabilities for hoisting winches and complete mechanical linkage testing, supporting dual electric elevation and manual emergency operation modes. Every unit undergoes full-stroke lifting/lowering cycle testing and self-lock verification prior to shipment, complete with fully traceable testing data.
2. Robust Overseas Delivery & After-Sales Support Ecosystem
Export packaging, shipping coordination, English documents, and remote installation guidance support overseas delivery. Model-specific spare-part lists, availability, and replacement guidance support long-term maintenance.
3. Dual-Category Process Heritage: High Mast Structural Performance Proven Across International Projects
Our surveillance and lighting pole experience supports established plate selection, forming, welding, NDT, and corrosion-protection processes. Project calculations and inspection records substantiate structural performance.
4. Fully Integrated Autonomous Production Chain for Controlled Quality
Production covers steel cutting, forming, welding, flange machining, corrosion protection, electromechanical assembly, and commissioning. In-house and subcontracted stages are controlled for quality and schedule.
5. Global Graded Anti-Corrosion Ecosystem Tailored to All Terrains and Climates
Carbon-steel protective systems are specified to the agreed environment and durability requirements. Stainless steel and aluminium receive material-specific surface treatments. Critical lifting components combine suitable materials, protection, lubrication, and maintenance.
Our lowering high-mast lighting systems come in two versions for different wind loads and application scenarios.
☛①Standard Lowering High Mast
Ideal for conventional scenarios such as plazas, parking lots, and sports fields. Built with standard pole walls and flanges to meet regular wind loads and basic lighting demands with high cost performance.
☛②Heavy-Duty Lowering High Mast
Optimized for harsh industrial environments including ports, yards, mines, and coastal areas. With thicker pole shafts and reinforced flange structures, it supports higher wind resistance and additional installation of PTZ cameras and monitoring sensors for stable long-term operation.
Quick jump: Commercial Terms | FAQ | Compatibility
| Item | Parameter |
| Pole Height | 9 m – 40 m (customizable per project) |
| Material | Carbon steel(Q235B/Q355B) / Stainless Steel(304/316L)/ Aluminum Alloy(6063‑T6/ 6061‑T6)(Customisable) |
| Manufacturing tolerances | Flange flatness ≤0.5mm, shaft straightness ≤L/750, bolt hole deviation ±1.5mm |
| Lifting System | Electric lowering with manual emergency operation or manual-only drive available; equipped with self-locking, braking, and top locking mechanism. |
| Lifting Speed | 3-5 m/min |
| Compatible Additional Equipment | LED floodlights, PTZ cameras, perimeter radar, environmental monitoring sensors |
| Surface Treatment | Carbon Steel: Hot-dip galvanizing (≥85μm) + outdoor electrostatic powder coating; Stainless Steel / Aluminum Alloy: Passivation / Brushing / Coating on request |
Factory Inspection | Rated lifting load and ring dimensions: stated for each model configuration. Motor supply, controls, and cable connection: configured to project requirements. 100% full-function lifting test for every unit before delivery |
Supported by an ISO 9001:2015 quality management system, we can adapt pole design, manufacturing quality control, corrosion protection, and technical documentation to project-specific standards and local requirements, supporting overseas project approval, procurement, and acceptance.
▲Structural Design & Wind Load Verification: Structural calculations can be performed in accordance with EN 40 / EN 1993, AASHTO, applicable AS/NZS standards, SASO requirements, or other project-specified codes. Design verification can incorporate site wind speed, equipment loads, mounting height, and environmental conditions.
▲Welding & Manufacturing Control: Welding procedures and quality control can be adapted to applicable EN 1090 execution requirements and ISO 3834 welding quality requirements, with corresponding process, inspection, and documentation controls implemented as required by the project.
▲Corrosion Protection: Hot-dip galvanizing and coating systems can be configured according to the project environment and required service life. Treatments can be specified to ISO 1461, ASTM A123/A123M, or other project requirements for standard outdoor, coastal, high-humidity, and high-salinity environments.
▲Engineering Documentation Support: Project documentation can include structural calculation reports, shop drawings, material certificates, welding records, galvanizing or coating inspection reports, dimensional inspection records, and factory quality documentation for client, consultant, or EPC review.
▲Multi-Market Project Support: We support project requirements across Europe, North America, the Middle East, and Asia-Pacific. Applicable design standards, inspection requirements, and document packages can be defined according to the project location and technical specification.
▲Compatible Luminaire Types
Compatible luminaires: high-mast LED floodlights. Ring and bracket configurations match luminaire weight, dimensions, mounting interfaces, and aiming requirements.
🔧Precision Customization: Arm length, tilt angle, bracket structure, and cable entry points can all be fully customized according to your luminaire specifications or CAD drawings.
▲Universal Camera Compatibility
①Cameras: Bullet, PTZ, Dome (Standard Interface), Laser PTZ.
②Sensors: Environmental, Traffic & Methane Gas Detection.
③Enclosures: Universal Security Power Supplies & Battery Enclosures.
🔧 Precision Fit: Custom hole drilling, crossarms, and flange patterns are available upon request based on CAD templates. Precision laser-cut top brackets can be tailored to specific camera footprints (e.g., Axis, Hanwha, Bosch), eliminating on-site drilling and accelerating installation.
Term | Detail |
| Customization | Supported — MOQ 1 unit |
| Lead time | Standard configuration: 3–4 weeks / Custom-engineered configuration: 4–5 weeks, from approved drawings and agreed order conditions. |
| Payment terms | 30% T/T advance · 70% before shipment · L/C at sight accepted |
| Trade terms | EXW: Specify named place FOB: Specify port of shipment CFR / CIF: Specify destination port |
| Inspection support | Third-party factory inspection by SGS / BV / TÜV welcomed |
| Samples | Available — sample cost credited against first production order |
⚡ Galvanic Corrosion Prevention: Select suitable fasteners and isolation measures for dissimilar metals while preserving required earthing and bonding continuity.
💧 Drainage & Sealing: Keep base drainage openings unobstructed; hand-hole covers and seals must remain intact. Never bury flange plates underground.
🛡️ Surface Protection: Protect coated, passivated, and brushed surfaces from mechanical scratches during installation. Repair damaged areas with material-matched touch-up treatment: touch-up coating for carbon steel/aluminium coated finishes, local passivation for stainless steel.
🔌 Grounding Requirement: Complete proper grounding and equipotential bonding in compliance with local electrical codes.
🏗️ Foundation Rules: Anchor bolts and concrete foundations must satisfy local wind-load requirements. Erect poles only after concrete has fully cured.
⚙️ Lifting-Lowering Commissioning: Follow the model-specific manual to inspect ropes, transmission, brakes, limits, and latches, and complete the prescribed trial operation and locking checks.
We provide custom wind-load calculation reports, 2D CAD drawings, installation manuals, and tender technical documents to support your global project approvals and customs clearance.
For general-purpose technical handbooks and safety guidelines, please visit our Download Center→
🚀 Rapid Delivery: Ship in 3–5 weeks, from approved drawings and agreed order conditions.
🔒 Secure Financing: Staged payments via T/T or L/C ensure financial control.
👤 Dedicated Management: A dedicated project manager provides real-time production updates.
📦 Reliable Packaging: Moisture-proof and shock-resistant packaging ensures safe container and ocean transit.
📄 Technical Documentation: Technical documents are supplied within the agreed order scope.
Product Definition & Applications
Q1: What types of projects are suitable for high-mast lighting systems?
A: Typical applications include container terminals, sports stadiums, highway interchange hubs, logistics parks, mining sites, large parking facilities, airports, and public squares—any open-area site requiring high-output, high-uniformity area lighting.
Q2: What is the difference between fixed-crown and lowering-crown lighting systems?
A: Fixed-crown systems permanently mount the luminaire ring at the pole top, requiring specialized lifting equipment for maintenance. Lowering-crown systems feature a built-in motorized winch mechanism that lowers the entire luminaire ring to ground level, enabling safe, low-cost maintenance without cranes or aerial work platforms. Lowering-crown systems are our standard product line.
Raising & Lowering System
Q3: Can the luminaire ring still be lowered during a power outage?
A: Manual emergency operation is available. Follow the model-specific procedure after checking the system condition. Pendant cable length and operating distance are defined in the configuration.
Q4: What is the hoisting speed of the luminaire ring?
A: Reference speed is 3–5 m/min. A 30 m one-way travel takes approximately 6–10 minutes, excluding unlatching, inspection, maintenance, and relatching.
Installation & Compatibility
Q5: Can the poles support additional equipment such as CCTV cameras and sensors alongside lighting?
A: Additional camera and sensor loads can be included in the structural design. Specify whether equipment is fixed to the shaft or mounted on the lowering ring, with the corresponding cabling and maintenance method.
Specifications are typical values for reference only under standard conditions — not a guarantee. Final performance shall be determined by project design calculations and factory test reports. Consult a local engineer before specifying.
